LLY内囊式高效纤维过滤器
LLY Inner capsule type high efficiency fiber filter
一. 简介Brief Introduction
LLY高效纤维过滤器是代纤维束过滤设备，早应用长纤维的过滤技术。由壳体、滤元、加压室、管系、加压室充排水系统等零部件组成。该设备运行时水自下至上通过滤层。清洗方式采用气水合洗，清洗效果好。该过滤器具有深层过滤效果，过滤速度快、截污容量大、出水水质好等优点。
The LLY high-efficiency fiber filter is the first generation of fiber bundle filtration equipment and the first application of long fiber filtration technology. It is composed of shell, filter element, pressure chamber, pipe system, pressure chamber filling and drainage system and other parts. Water passes through the filter from bottom to top when the equipment is in operation. The cleaning method is combined with air and water, and the cleaning effect is good. The filter has the advantages of deep filtration, fast filtration speed, large pollution capacity and good effluent quality.
设备所有接口法兰压力等级均为PN1.0Mpa；
设备供货到一次接口法兰为止，阀门由用户自理。
供货范围包括进、出水压力表，进、出水取样阀门。
The pressure grade of all interface flanges of the equipment is pn1.0mpa;
The device is supplied to an interface flange, and the valve is self-reliant.
The scope of supply includes inlet and outlet pressure gauges, inlet and outlet sampling valves.
二. LLY内囊式式纤维过滤器规格性能表LLY Inner capsule type high efficiency fiber filter specification table
设备规格型号 model number | LLY800 | LLY 1000 | LLY 1500 | LLY 2000 | LLY 2500 | LLY 3000 |
设备直径（：mm） Equipment diameter | 800 | 1000 | 1500 | 2000 | 2500 | 3000 |
流量（m3/h） maximum flow | 15 | 20 | 49 | 91 | 149 | 210 |
滤水面积（m2） the filter area | 0.5 | 0.78 | 1.77 | 3.14 | 4.9 | 7.06 |
过滤速度（m/h） filtration velocity | 20～30 | |||||
滤层高度（m） filter layer height | / | |||||
操作压力（Mpa） operating pressure | 0.6 | |||||
截污容量（kg/m3） sewage removal capacity | 10～15 | |||||
过滤前水质 pre-filtration water quality | 悬浮物 suspended solids（mg/L） | 20 | ||||
浊度 turbidity（NTU） | 20 | |||||
过滤后水质 filtered water quality | 悬浮物 suspended solids（mg/L） | ≤2 | ||||
浊度 turbidity（NTU） | ≤2 | |||||
设备参考重量（≈t） reference weight of equipment | 1.6 | 3.0 | 4.2 | 5.8 | 7.3 | 9.5 |
注：表中设备规格仅供参考，具体应以双方签字的设计图纸为准。 Note: the equipment specifications in the table are for reference only, and shall be subject to the design drawing signed by both parties. 详细资料，请联系本公司索取。 Please contact us for further information.
| ||||||
